19-22 Way Flush Mount DB Board

SKU: VBM1922FL

  • Adjustable Cover & DIN Rail for an Easy & Level Installation
  • Effortless Push-To-Open Mechanism
  • Metal Tray Provides Strength & Durability
  • Label Circuits Clearly and Neatly for Easy Identification
  • Flush Mount
  • 19-22 Way DB Box
  • Adjustable Din Rail
  • 10 X 20mm & 8 X 25mm & 4 X 32mm Knock out Sizes
  • 436mm X 192mm X 77mm Size
  • Metal Tray, Plastic Cover, Copper Bar

R 389.00 ex. VAT R 447.35 in. VAT

Details

The VBM1922FL is an IP20-rated 19-22 Way Flush Mount distribution board, with a compact 1-row height, it can accommodate up to 22 individual 18mm modules, providing an efficient and reliable electrical distribution solution for your space. Crafted from high-quality, powder-coated iron, the durable metal tray ensures strength and longevity. Conforming to South Africa compliance standards IEC61439 and IEC61000, the VBM1922FL distribution board is equipped with an Earth & Neutral Bar, offering enhanced safety and reliability in electrical installations. The adjustable DIN rail and front cover simplify the installation process, ensuring a level and secure setup. Additionally, included distribution board labels make circuit identification easy, helping to maintain a tidy and organised electrical system. This VBM1922FL distribution board is the ideal choice for those seeking a robust, efficient, and organised electrical solution.

Specifications:

Function

Range

Dimensions



Overall

466 x 210 x 97mm

Wall

436 x 192 x 77mm

Knock Outs



Top

5x 20mm, 2x 25mm & 2x 32mm

Bottom

5x 20mm, 2x 25mm & 2x 32mm

Right Side

2x 25mm

Left Side

2x 25mm

Material



Cover

High Quality Polycarbonate Plastic (PC)

Tray

Metal for increased strength and durability

Earth/Neutral Bar

Copper

IP Rating

IP20

Warranty
