360° Microwave Motion Sensor - IP54

SKU: MS362

  • Detects even the slightest motion
  • 3 – 2000 LUX (Adjustable)
  • Detection Area
    • 360° Ceiling Installations
    • 120° Wall Installations
  • 15m Detection Distance
  • Automatically turns on lights when motion and body heat is detected
  • Time-delay and ambient light adjustment
  • Identify day and night automatically
  • Rated Load
    • 1200W (Incandescent Lamps)
    • 600W (LED / CFL)
  • IP54 Rating - Outdoor & Indoor Installations

R 479.00 ex. VAT R 550.85 in. VAT

Details

The MS362 automatically turns on lights or any electrical device within the sensors rated load. It detects through obstacles like doors, glass panels, and thin walls, with a 360° detection range when mounted on a ceiling and 180° when wall mounted, and adjustable settings for time, Lux level and sensitivity. Easily integrated into new or existing installations, it excels in detecting subtle movements over large areas compared to PIR sensors.With an IP54 rating, the sensor is suitable for both indoor and sheltered outdoor installations, offering protection against limited dust ingress and water splashes from any direction. Installation must be done by a qualified electrician.

Application:

  • Ideal for home use and in educational and commercial properties
  • Detects through doors, glass panes or thin walls

Specifications:

Function

Range

Detection Area

Ceiling Installation

Wall Installation



360°

180°

Detection Distance

Ceiling Installation

Wall Installation



5m - 15m (Adjustable)

5m - 15m (Adjustable)

Detection Motion Speed

0.6 to 1.5m/s

HF System

5.8GHz CW Radar, ISM Band

Ambient Light

<3 to 2000 Lux (Adjustable)

Installation Height

Ceiling Installation

Wall Installation



1m to 3.5m

1m to 3.5m

Voltage

220 to 240V AC

Power Frequency

50/60Hz

Rated Load

Incandescent

LED / CFL



1200W

600W

Time Delay

10 sec (±3 sec) to 12 min (±1 min)

Power Consumption

<0.9W

Mounting

Ceiling & Wall Mount

Working Temperature

-20°C to 40°C

Working Humidity

<93% RH

IP Rating

IP54 (Indoor & Outdoor Installation)

Standards

IEC 60669-1 / 60669-2-1

AS/NZS 60669.1 / 60669.2.1

Safety Rating

Warranty

Accessories:

  • Screws
  • Instruction Manual
