The 100mm x 100mm (4×4) monoblock socket outlet has been tested and approved to the required standard of IEC60884-1 & IEC60884-2-3 in conjunction with SANS164-0 & SANS164-1.
The socket outlet has also been issued with an LOA (Letter of Authority) from the NRCS (National Regulator for Compulsory Specifications) allowing for the sale of the product in South Africa.
The socket outlet is rated at 16A, 250V and is thus able to handle any load drawing a maximum of up to 16A. The contacts are made from high quality copper to ensure the
safest connection by improving conductivity and therefore reducing heat which is caused due to a higher resistance from other accepted materials such as brass.
The socket is made from a mix of high quality plastics including flame retardant polycarbonate for an attractive finish and durable finish and the back is made from flame
retardant polypropylene to ensure strength and slightly more flexibility to assist if wall boxes are not in straight
Cover Plates that fit:
V6208
VB6211
Additional information
Conductive Material:
Copper
Plastic Type:
Flame retardant polycarbonate and polypropylene mix
